Features

•

Compression molded from our exclusive solid Vikrell

material

•

Convenient shelving and acrylic towel bar on back

wall

•

Modular 4-piece design

•

Tongue-and-groove 4-piece modular design allows for

easy ″snap together″ installation

•

Durable swirl-gloss ﬁnish

•

10-year consumer/3-year commercial limited warranty

•

Caulk required for installation

•

Allows for future attachment of grab bars

•

60-1/4″ (1530 mm) x 31-1/2″ (800 mm) x 74″ (1880

mm) complete unit rough-in dimensions include

ﬂange

•

60″ (1524 mm) x 30″ (762 mm) x 72-3/4″ (1848 mm)

complete unit ﬁnished dimensions

Codes/Standards Applicable

Speciﬁed model meets or exceeds the following:

•

CSA B45.5/IAPMO Z124

•

ASTM E162

•

ASTM E662

•

HUD, UM Bulletin 73A

•

NAHB Research Foundation, Inc.

60″ BATH/SHOWER SYSTEM WITH

BACKER BOARDS

61040116

ALSO 61040126

Colors/Finishes

•

0: White

•

Other: Refer to Price Book for additional colors/ﬁnishes

Speciﬁed Model

Model Complete Unit Description Colors/Finishes

61040116 60″ bath and wall surround with backer boards, left drain ❑ 0 ❑ Other_____

61040126 60″ bath and wall surround with backer boards, right drain ❑ 0 ❑ Other_____

Model Wall Component Description Colors/Finishes

61044106 Complete wall set with backer boards ❑ 0 ❑ Other_____

ALL PRO

Page 1 of 2

1065811-4-

For more information

visit SterlingPlumbing.com

or call 1-800-STERLING
